RAMFAN
18V EX50Li
1hp BrushlessPPV
Positive Pressure Blower for enclosed structures or spaces.
For when power and water resistance is not a priority, the RAMFAN EX50Li-18V is designed for small volume desmoking of rooms or small structures—compatible with the common 18 V commercial batteries of your extrication and handheld power tools. Use the batteries and chargers you already have in service. Integrated LED Flood Lights illuminate the entry point of a structure during night operations and provide visual low voltage warning.
Key Features
| Rollover Protection System (ROPS) Update | Prioritizing user safety, our fan detects falls, instantly stopping the impeller to minimize injury risk and impeller failure. |
|---|---|
| Low Voltage Warning | Improve your situational awareness day or night; as batteries deplete to <5 minute runtime remaining, front LEDs flash - any control input cancels warning. |
| Upgraded Frame | Robust aircraft-grade aluminum tubing, improved molded cord holder, and rubber feet placement for downholw and attic venting. |
| Compatible with Milwaukee high capacity battery packs | Since February 2025 (serial prefix: 8920015), the M18 FORGE 12Ah battery packs are compatible with the EX50Li-18V. |
Product Features
- Integrated scene lights
- Compatible with Milwaukee & DeWalt high capacity battery packs
- Confined Spaces
- Removable wheels.
Designed for small areas
18V for small flow desmoking of rooms or small residential structres—compatible with the commercial batteries of your extrication and handheld power tools.
18V Diagram
Width: 21″ · Height: 22″ · Depth: 16″
Vehicle Mount: 22″ × 12.85″
Technical Specifications
EX50Li (18VDC) 18″ / 46 cm
| Order# | EL5518D (DeWalt Compatible) EL5518M (Milwaukee Compatible) |
|---|---|
| Motor | 1 hp BrushlessPPV™ |
| Runtime @ Max. Speed | DC: 26 minutes - 8 Ah batteries 40 minutes - 12 Ah batteries 50 minutes - 15 Ah batteries AC: unlimited |
| Input Voltage Range | Universal Input: 85 - 264 VAC, 1Ø, 50/60 Hz |
| Battery System | 18V, 216/12Ah Milwaukee 20V, 270/15Ah DeWalt |
| Dimensions | 22 x 21 x 16 in / 56 x 53 x 41 cm 22 x 21 x 12 in / 56 x 53 x 30 cm (wheel kit removed) |
| Weight | without batteries: 54 lbs / 24 kg |
| Noise | < 90 dB |
| Operating Temp Range | -4°F to 105°F / -20°C to 40°C |
| Tilt | -6° to +34° |
| Approvals | CE AMCA |
| AMCA Verified Airflow | |
| DC Power Supply | 10,352 cfm (17,585 m³/hr) |
